Powermax30® XP, Plasma Cutting : 4,5 m (15') Duramax LT torch, part# 088081,

Brand: Hypertherm
Alruqee Code: WSPCSHY088081
Supplier Code: 088081

SR0.00 SR0.00

Power supply 120-240 V CSA1 , 4,5 m (15') Duramax LT torch, part# 088081 The Powermax30® XP is a highly portable plasma cutting system that can handle a wide range of applications. A unique “two-in-one” design provides high-power capability for thick metal cutting, as well as the FineCut® consumables for detailed, thin metal cutting. The versatile 30 amp system uses air or nitrogen to cut electrically conductive metals, such as mild steel, stainless steel, or aluminum.

quantity

Easy to use

System includes everything you need to get you cutting quickly and easily
Small size and light weight let you take the Powermax30 XP just about anywhere
Plug into any 120 or 240 V power (convenient Auto-Voltage™ technology and plug adapters included)

Input voltages	120-240 V, 1-PH, 50/60 Hz
Input current @ 3.8 kW	120-240 V, 1-PH, 25-18.8 A
Output current	15-30 A
Rated output voltage	125 VDC
Duty cycle @ 40°C (104°F)	35%, 240 V / 20%, 120 V
Open circuit voltage (OCV)	256 VDC
Dimensions with handles	356 mm (14.0") D; 168 mm (6.6") W; 305 mm (12.0") H
Weight w/ 4,5 m (15') torch	CSA: 9.7 kg (21.4 lbs)
Gas Supply	Clean, dry, oil-free air or nitrogen
Recommended gas inlet flow rate / pressure	113.3 l/min (4 scfm) at 5.5 bar (80 psi)
Input power cable length	3 m (10')
Power supply type	Inverter - IGBT
Engine drive requirement	5.5 kW for full 30 A output
Certifications	CSA-certified for use in the Americas and Asia, except China
Warranty	Power supplies have a 3-year warranty and torches a 1-year warranty.
